Transitioning Oil & Gas Wells to Renewable Geothermal Energy

Infinity Turbine 2016 ROT IT50

Figure 1:  Radial Outflow Turbine Generator – Organic Rankine Cycle – ORC Turbine (1)

Existing oil and gas wells offer access to untapped sources of heat which can be converted to electricity or used for other energy intensive purposes.  This includes many abandoned wells, which can be reactivated as power sources.  These wells, in many cases “stranded assets” have been drilled, explored, and have roads built for access.  This makes re-utilization of existing infrastructure cost-effective while minimizing harm to the environment associated with exploration.

In a recently published article in Alberta Oil, an oil & gas industry magazine they point out many of the benefits of converting existing and abandoned wells to geothermal energy.

A recent Continental Resources-University of North Dakota project in the Williston Basin is producing 250 kW of power from two water source wells. The units fit into two shipping containers, and costs US$250,000. This type of micro-generation is prospective in Alberta, and a handful of areas also have potential for multi-MW baseload power production.

In addition to producing power, we can use heat for farming, greenhouses, pasteurization, vegetable drying, brewing and curing engineered hardwood. Imagine what Alberta’s famously innovative farmers and landowners would accomplish if they were given the option to use heat produced from old wells on their properties. Northern communities, where a great many oil and gas wells are drilled nearby, can perhaps reap the most benefits of all. Geothermal can reduce reliance on diesel fuel, and provide food security via wellhead-sourced, geothermally heated, local greenhouse produce. (2)

Water can be recirculated by pumps to extract heat from the earth, and through heat exchangers be used as a source of energy for various forms of machines designed to convert low grade waste heat into electricity.  The Stirling Cycle engine is one such mechanical device which can be operated with low grade heat.  However recent developments in the Organic Rankine Cycle (ORC) engine seem to hold the greatest promise for conversion of heat to electricity in these installations.

In a “boom or bust” industry subject to the cycles of supply and demand coupling a new source of renewable energy to resource extraction makes sense on many fronts.  It could be an economic stimulus not only to the province of Alberta, but throughout the world where oil and gas infrastructure exists, offering new jobs and alternative local power sources readily available.

References:

(1)  http://www.infinityturbine.com/

(2)  http://www.albertaoilmagazine.com/2016/10/geothermal-industry-wants-abandoned-wells/

Related Blog Posts:

  1. https://duanetilden.com/2016/01/14/alberta-energy-production-and-a-renewable-future/
  2. https://duanetilden.com/2014/12/21/renewable-geothermal-power-with-oil-and-gas-coproduction-technology-may-be-feasible/
  3. https://duanetilden.com/2015/07/25/a-new-era-for-geothermal-energy-in-alberta/
  4. https://duanetilden.com/2015/07/27/oil-well-waste-water-used-to-generate-geothermal-power/
  5. https://duanetilden.com/2013/10/29/supercritical-co2-refines-cogeneration-for-industry/
